LV DALI - LV150W48CG2 DALI

KGP LV150W48CG2 DALI — 150W constant voltage LED driver, 48V output, DALI dimmable.

Electric parameters

• Rated Power: 45-150W
• Input Voltage: 220-240VAC 50/60HZ
• Output Voltage: 48V
• Output Current: 0.937-3.125A
• Efficiency: 92%
• Power Factor: 0.95
• Ripple: <480mV PK-PK (0.5%)
• Dimming: DALI-2 / PUSH DIM, 1-100%
• Protection: IP20, Class II, SELV

Warranty

• 5 Years

Certificate

• SAA/RCM/CE/UKCA/EAC

Housing No/Dimension

• 350*30*18mm (L*W*H)
